PASO AW5612 120W amplifier

120W amplifier

The AW5612 power unit is equipped with an RJ45 input for connection with preamplified B711-G call bases via a simple CAT.5E SFTP shielded cable. On the rear terminal block there is a special input (TEL/EMERG) balanced with a transformer and with automatic activation of precedence (VOX). The adjustment of the level and the intervention threshold are present on the rear panel. This input can be used to connect to the appropriate audio output of a telephone exchange. This device is characterized by a large number of protection devices against overloads and short circuits (circuit limiting the peak of the output current, thermal switch located inside the power transformer, restorable thermal switch placed in contact with the power transistor heatsink, network fuses). In addition, it is equipped with a cooling fan, with automatic speed control depending on the temperature of the heatsinks on which the power devices are applied. Note: the AW5600 series amplifiers are equipped with an electronically balanced line input/output with a double XLR socket; a female and a male socket in order to facilitate the cascade connection between multiple power units. To connect a sound source directly, a second unbalanced input can be used via a double RCA socket for the use of standard stereo cables.
