PASO AX3512 120W amplifier mixer

120W amplifier mixer

The two models AX3506, 60 W, and AX3512, 120 W, have excellent functional characteristics and are characterized by an exceptionally favorable price/performance ratio. The wide configuration option makes each of these devices a versatile “system” able to cover the needs of any small and medium-sized plant. Three balanced microphone inputs with Phantom power to which is added an input for the B711-G microphone call bases. Two auxiliary inputs for sound sources (Tape, CD) selectable by front control. On the rear terminal there is an audio input with automatic priority activation (VOX); level and intervention threshold are adjustable from the rear panel. This input can be used to connect to the appropriate audio output of a telephone exchange. Through the previous contact, it is possible to activate the priority of the microphones on the auxiliary sources with the simultaneous sending of the warning signal (Din-Don). A front VU-meter provides a clear indication of the power output and of any overload situations. The amplifiers are equipped with electronic protection against short circuits in the speaker line. Standard 19” rack mount using special AC3500 brackets.

FUNCTIONAL CHARACTERISTICS: 2 mic. phantom power inputs (XLR). MIC 1, automatic precedence function (VOX), adjustment of the intervention threshold Microphone input (XLR) with Phantom power supply or B711-G microphone stations (RJ45) MIC/PH/LINE input with relative selector 2 auxiliary inputs for sound sources (TAPE/CD) Phone/Emergency audio input for priority call with adjustable intervention threshold and sensitivity Frontal adjustment of the microphone input level and front auxiliary of the general volume and of the high and low tones. constant voltage 50/70/100 V or at 8Ω impedance Auxiliary VU-meter LED line output for immediate verification of the power emitted Micro switches to set the priorities and functions of the inputs Word filter insertable/disinsertable on all microphone inputs Contacts to activate a warning signal (DIN-don) input with regulation of the 230/115 Vac and 24 Vac power supply level
