PASO AX6120 120W three-zone amplifier mixer

120W three-zone amplifier mixer

Versatility, ease of use, robustness and reliability characterize this series of integrated amplifiers, designed for a wide range of applications in the field of sound diffusion for both commercial and industrial use. Three output lines (zones), CAT5 connection with microphone stations for zone calling, priority emergency call on a single zone or group of zones, provision for a USB/SD card music module are, in fact, just some of the many functions offered by the AX6000 series. An internal CPU that can easily manage the multiple functions of the device and special micro-switches located on the back allow you to select the desired operating mode. All models are equipped with 5 inputs with independent front level controls and with professional XLR connectors equipped with mechanical restraint; the first two are of the microphone type, electronically balanced, with Phantom power (input 1 with automatic VOX activation); the third can be used as a microphone input or as an input for the PMB106-G microphone stations (RJ45 connector) with the possibility of making zone calls; the last two are independently configurable, as microphone inputs (with or without Phantom power supply) or as line inputs. For the connection of music sources, there are two auxiliary inputs (CD and TAPE) with standard input levels and a double RCA socket for the use of standard stereo cables. A special Phone/Emergency audio input with automatic activation (VOX) can be used for a priority call. If the system requires acoustic correction, any equalizer or antilarsen device can be connected to the PRE OUT and PWR IN sockets after switching the appropriate control diverter. The front panel has a compartment for inserting an optional AC6000 module that allows the reading of external devices such as SD/MMC cards and USB storage units, to be used as a music source. All amplifiers guarantee high reliability thanks to electronic protections against overload currents and overtemperatures of power devices. They are also equipped with a cooling fan, with automatic speed control depending on the temperature.

FUNCTIONAL CHARACTERISTICS: 2 balanced/unbalanced microphone inputs with Phantom power Microphone input or PMB series microphone stations 2 MIC/PH/LINE inputs with relative selector 2 auxiliary inputs for sound sources (TAPE/CD) Phone/Emergency audio input for priority call with adjustable intervention threshold and sensitivity Frontal adjustment of microphone and auxiliary input levels Frontal adjustment of general volume and high and low tones Preparation for insertion from the front of a USB/SD CARD reader module (AC6000) Speaker line output at constant voltage 50/70/100 V or 8 Ω impedance 3 output lines (zones) Balanced line output for connection to other amplifiers Output/input for connection to LED Vu meter audio processors for immediate verification of the power emitted Microswitches to set the operating modes Word filter insertable/disconnectable on all microphone inputs Contacts to activate input and override precedence “Music On Hold” output with output level adjustment (output of the selected auxiliary signal) Warning signal (DIN-Don) with level adjustment Front keys for selecting music listening areas 230/115 Vac and 24 Vcc power supply
