COOPER CSA FIRE MARDF6 2 RELAY BOARD FOR 'ALL' AND 'GST' OUTPUTS

2 RELAY BOARD FOR 'ALL' AND 'GST' OUTPUTS

Cooper MARDF6 Auxiliary Output Module The MARDF6 is an auxiliary output module designed for use with the DF6000 panel. Installation Mount the PCB using the supplied plastic feet The PCB must be mounted as physically close as possible to the external equipment Connect the PCB The end of line monitoring devices are embedded inside the MARDF6 PCB, remove and discard the end of line devices from the relevant outputs of the DF6000 panel Connect 24V to the PCV, this can be derived from the auxiliary output of the DF6000 panel
