COOPER CSA FIRE CIOP4 4 INPUTS 4 OUTPUTS RELAY BOARD
- MT Code
- CSA_CIOP4
- Manufacturer Code
- CIOP4
- Brand
- COOPER CSA FIRE
4 INPUTS 4 OUTPUTS RELAY BOARD
Cooper CIOP4 4-way mimic relay board with 4 inputs and 4 outputs These addressable synoptic relay cards, CIOP4 and CIOP8, are 4- and 8-way soft-addressing output modules, which incorporate integrated short circuit isolators. Both the CIOP4 and CIOP8 synoptic relay boards are fully compatible with the current range of Cooper smart addressable control panels. The units are suitable for low-voltage switching (24 V DC at 1 A maximum), through a series of relay contacts without restraint. The flexibility of these modules is further enhanced by the fact that each output can be programmed for a series of activations such as deactivation, failure, fire, panel test, early warning zone test, fire transmission equipment, fire protection equipment and recovery with up to 16 different trigger sources per output. The trigger source can be global, per central, per loop, per zone, or per address. Logic is available in both OR and AND functions. These units have 4 additional inputs that can initiate a reset, mute, evacuate and test function. They can be programmed using the CF3000 programmable site installation software and downloaded using the RS232 port. Main features: Ring powered The units can be soft or hard addressed Integrated short circuit isolator Single address Version 4 inputs, 4 outputs Version 4 inputs, 8 outputs The PCB version incorporates 4 inputs: — Restore — Silence — Evacuate — Test 16 settings per output Types of activation: fire, fault, disabling, test, early warning, FRE, FPE, recovery Activation source: global, for control unit, for loop, by zone, by address Logical functions (OR & AND) Benefits: Fast and simple to install Pluggable terminals for easy wiring Programmable via on-site installation software Convenient installation solution
Codice Produttore | CIOP4 |
---|---|
Brand | COOPER CSA FIRE |
