PASO PA1060 60W USB/SD-Card Receiver

60W USB/SD-Card Receiver

A multifunction module with digital FM tuner, an MP3 file player for USB/SD-MMC card, an amplifier mixer and the wide configuration options make the PA1060 a versatile sound distribution system capable of covering the needs of any small and medium-sized system. The XLR jacks on the rear panel are independently configurable as microphone inputs (with or without Phantom power) or as line inputs: the mode selection is obtained through the relevant three-position diverters. Each of these inputs has its own level control to appropriately dose the amplitude of the various signals. In addition, the INPUT1 microphone input is equipped with the automatic precedence function (VOX): speaking to the microphone connected to this input, all musical and microphone inputs will be automatically muted. For connection to external music sources, an auxiliary input with double RCA socket is provided for the use of standard stereo cables. All dynamic-type microphones and B701-MG microphone bases can be connected to the compact systems of the PA1000 Series. A front terminal block, on the rear panel, makes it possible to silence the signals coming from the MP3 player, the tuner and the auxiliary input. In the event that the system, for particularly difficult environments, requires acoustic correction, it is possible to connect any equalizer or antilarsen device to the PRE OUT and PWR IN sockets. High reliability is guaranteed thanks to electronic protections against overload currents and overtemperatures of power devices. In addition, it is equipped with a cooling fan, with automatic speed control depending on the temperature.

Functional features: - MP3 file player module via USB, SD or MMC card. - Digital FM tuner. - No. 3 MIC inputs. /LINE with relative selection of the operating mode. - n. 1 VOX input (INPUT 1). - n. 1 auxiliary sound source input (TAPE/CD). - Frontal adjustment of the level of each microphone and auxiliary input. - Frontal adjustment of overall volume and of high and low tones. - XLR jacks for connecting dynamic microphones and/or B701-MG stations. - Speaker line output terminal with constant voltage 25/70/100 V or with 4W impedance. - Terminal block for activating the microphone inputs first. - Output/input for connecting to audio processors. - Unbalanced line output for connection to other amplifiers. - Vu-meter LED for a clear and immediate verification of the power output. - Terminal block for direct current supply (24 VDC). - Selectable mains supply (230/115 Vac). - Standard 19” rack mount using optional brackets.
