EELECTRON KP10C02KNX-1 9025 KNX CAPACITIVE NUMERIC KEYPAD FOR CONTROL

The EELECTRON KP10C02KNX-1 product is a KNX capacitive numeric keypad designed for managing access control and other building automation functions.

Key Features

This device has 10 capacitive channels, numbered from 0 to 9, and can be configured using the ETS software to communicate with the KNX Data Secure protocol.

Installation and Design

The keyboard can be installed in a box of 2 or 3 modules and has glass covers, available in black or white, with backlights for numbers.

Temperature Control

The device includes a two-stage temperature controller with an integrated PI controller, allowing you to manage heating, cooling, valves and 2- and 4-pipe fan coils. An additional NTC temperature sensor (eelectron codes TS01A01ACC or TS01B01ACC) can be connected for direct temperature measurements.

Feedback and Indications

The numeric keyboard integrates an RGB LED bar on the front, configurable to display the status or anomalies of the system. In addition, it has a buzzer that can be enabled or disabled to provide acoustic feedback when a key is pressed.

Additional Features

The device includes a 2-pin rear connector that can be configured as a digital or analog input, offering flexibility in connections.

Applications

The system is ideal for residential, hotel and commercial applications, ensuring intelligent automation and energy savings in buildings.

• Compatible with the main standards (British, German, Italian, etc.).
• Configurable through the ETS software.
• Communication with the KNX Data Secure protocol.
