INIM FIRE SE138EA-H Electrochemical Ammonia Detector - 4÷20mA output and 4 relay outputs
- MT Code
- INM_SE138EA-H
- Manufacturer Code
- SE138EA-H
- Brand
- INIM FIRE
Ammonia detector (electrochemical). 4÷20mA output and 4 relay outputs. Measurement range 0÷300 ppm. ATEX ZONE 1. Suitable for installation in environments with difficult environmental conditions.
Gas detectors in explosion-proof enclosure for use in areas with the presence of potentially explosive atmospheres, certified CESI 03 ATEX 323 X (EN60079-0 and EN60079-1) are characterized by the following ATEX marking (Directive 2014/34/EU)
12÷24Vcc power supply - Atex marking: II 2G Ex d IIC T6 Gb - No. 3 solid state alarm relay. MAX 24V/1A SPST resistive load - No. 1 solid state fault relay. MAX 24V/1A SPST resistive load - Alarm levels (Relay) programmable via Dip-Switch - No. 1 linear output 4÷20 mA - Polarized plug-in terminals
Gas detected: Ammonia - Cartridge change: ZSEA2/EX - Measuring range: 0÷300 ppm - Calibration bottle: BO501 - Average life in clean air: 2 years
Codice Produttore | SE138EA-H |
---|---|
Brand | INIM FIRE |
