INIM FIRE TS282IC2-H Infrared Detector for Carbon Dioxide Output 4÷20mA

MT Code: INM_TS282IC2-H
Manufacturer Code: TS282IC2-H
Brand: INIM FIRE

Description

Carbon Dioxide Detector (infrared). 4÷20mA output. Measurement range 0÷5000ppm.

Power supply: 12÷24 Vcc - Degree of protection: IP65 (IP44 for SE136IC2 and TS210IC2) - No. 3 alarm relays. MAX 24V/1A SPST resistive load (SE136IC2 only) - No. 1 fault relay. MAX 24V/1A SPST resistive load (SE136IC2 only) - Alarm levels (Relay) programmable via Dip-Switch (SE136IC2 only) - No. 1 linear output 4÷20 mA - No. 5 LEDs show the operating status (red: alarm; green: power supply; yellow: fault) - Polarized plug-in terminals

Detected Gas: Carbon Dioxide - Replacement cartridge: ZSIC2-H/IP - Measuring range: 0÷5000 ppm - Calibration bottle: B0404 - Average life in clean air: 5 years
