INIM FIRE TS293IC2 Carbon Dioxide Detector (infrared) - Output 4÷20mA

MT Code: INM_TS293IC2
Manufacturer Code: TS293IC2
Brand: INIM FIRE

Description

Carbon Dioxide Detector (infrared). 4÷20mA output. Measurement range 0÷5 VOL percentage. ATEX ZONE 1

Gas detectors in explosion-proof enclosure for use in areas with the presence of potentially explosive atmospheres, certified CESI 03 ATEX 323 X (EN60079-0 and EN60079-1) are characterized by the following ATEX marking (Directive 2014/34/EU)

Power supply: 12÷24 Vcc - Atex marking: II 2G Ex d IIC T6 Gb - No. 1 linear output 4÷20 mA - Polarized plug-in terminals

Gas detected: Carbon dioxide - Replacement cartridge: ZSI01C/EX - Measuring range: 0÷5% Vol. - Calibration bottle: B0405 - Average clean air life: >5 years

Data Sheet
