PASO CS2080 Control center for discussion-only system

Control center for discussion-only system

The simple to install, low-cost CS2080 conference system requires no programming or room assistant to work.

It is an open-access discussion system, with priority intervention by the President microphone (moderator). Suitable for conferences with a maximum of 80 participants including the president. The heart of the system is the CS2080 control and power supply unit. Created to manage, without room assistant, small discussion-only systems. The versatility of the output connections and the front level controls, independent for each audio input signal, are the strengths of this control unit. It powers up to 80 stations with the availability of 4 RJ45 outputs for the various cascade connections of the stations (shielded Cat5e SF/UTP cable). 'MIC'/'AUX IN' input for connecting additional sources inside the conference, such as a wired microphone, radio microphone receiver or other sound sources. Possibility to insert a 12 V phantom power for the 'MIC' input. Dual 'IN' and 'OUT' phono jacks for connecting a recorder. 'BOOSTER OUT' (XLR) output socket to which you can connect a power unit for room sound broadcasting.

FUNCTIONAL SYSTEM CHARACTERISTICS: Maximum total number of usable seats equal to 80 Up to 79 seats Delegate: B2080-DG President's Station B2080-PG Open Conference (simultaneous management of several seats) Speech by the President in conversation or priority mode Easy cascade connection using CAT5 shielded cables Up to 4 connection lines (maximum 20 units per line, maximum 100 meters from the control unit to the last connected unit) Connection of additional sources and of an audio recorder Three independent volume adjustments (signal coming from the units, from the 'TAPE' input and from the 'MIC/AUX IN' inputs) Connection to a power unit for room sound distribution
