EELECTRON 9025GL03P03 LINE SERIES OUTDOOR PANEL GLASS + RGB BLACK

EELECTRON 9025GL10W03 Product Description

The KNX® 9025GL10W03 capacitive switch from the EELECTRON LINE series is a versatile and highly configurable device, designed to meet control and management needs in residential and commercial environments.

Key Features

This switch is available in a 10-channel version and can be mounted in boxes of 2 or 3 modules, compatible with British, German and Italian standards.

Dimensions and Assembly

• Device dimensions: 96 x 96 x 36 mm (2-module version) and 96 x 126 x 36 mm (3-module version)
• Mounting in standard built-in boxes

Food and Communication

• EIB/KNX bus power supply: 21 ÷ 32 Vdc
• Maximum consumption: 30 mA
• Communication via KNX Data Secure protocol

Control Functionality

• Each button can be configured to manage on/off commands, dimmers, control of shutters and blinds, recall of scenes and sequences of objects
• Integrated two-stage thermostat with PI controller for controlling heating, cooling equipment, valves and 2- and 4-pipe fan coils

Sensors and Inputs

• Integrated temperature sensor and 2-pin connector configurable as digital or analog input
• Possibility to connect an additional NTC temperature probe (eelectron codes TS01A01ACC or TS01B01ACC)

User Interface

• Capacitive bar with swipe function for implementing programmable KNX functions
• Freely configurable RGB LED bar for displaying states or other quantities available on the KNX bus
• Customizable glasses with illuminated icons and associated functions

Conditions of Employment

• Operating temperature: -5 °C +45 °C
• Storage temperature: -20 °C +55 °C
• Relative humidity (non-condensing): max. 90%

Logic and Programming

• 32 logical blocks to create complex logical and algebraic expressions
• Use of predefined algorithms for proportional temperature and humidity controls
• Configurable through the ETS® application program
