TECNOCONTROL TS593EO Exd ATEX electrochemical detector with display 4-20mA for O2

MT Code: TCC_TS593EO
Manufacturer Code: TS593EO
Brand: TECNOCONTROL

Description

Exd ATEX electrochemical detector with display 4-20mA for O2

Gas detectors in explosion-proof housing for use in areas with presence of potentially explosive atmospheres, CESI 03 certificates ATEX 323 X (EN60079-0 and EN60079-1) are characterized by following ATEX marking (Directive 2014/34/EU)

• Power supply: 12÷24 Vcc
• Atex marking: II 2G Ex and IIC T6 Gb
• No. 1 linear output 4÷20 mA
• Polarized plug-in terminals
• Equipped with a display with real-time display of gas concentration
• Non-intrusive calibration

Detected Gas: Oxygen Replacement
cartridge: ZSI01/EX Measuring
range: 0÷ 25% Vol.
Calibration cylinder: B0416 Average
life in clean air: >5 years

Data Sheet
