ALLMATIC 12007103 IND4000 V/I WITH THREE-PHASE INVERTER WITH B.RO22W Irreversible oil soaked motor for intensive use, with M4 transmission gear and self-ventilation
- MT Code
- ALL_12007103
- Manufacturer Code
- 12007103
- Brand
- ALLMATIC
IND4000 V/I WITH THREE-PHASE INVERTER WITH B.RO22W
IND4000 has mechanical components in metal and bronze and an advanced system for the maximum cooling efficiency that guarantee optimal use even in more critical situations, always maintaining a fluid and precise movement, thank you too to the revolutionary electronic control systems integrated. Available in 230 Vac three-phase version (IND4000V/I) and 400Vac three-phase (IND4000V/T). Built to last. Ideal operator for industrial sliding gates up to 4000 Kg.
Irreversible oil-soaked motor for intensive use, with M4 transmission gear and self-ventilation. Complete with INVERTER control unit.
230Vac single-phase power supply for control unit. 230Vac three-phase power supply (triangle connection) for motor.
B.RO22W LED 2ch receiver included
| Feature | Value | Unit of measure |
|---|---|---|
| Codice Produttore | 12007103 | |
| Brand | ALLMATIC | |
| Operatore | IND4000V/I | |
| Alimentazione | 230 | Vac 50Hz |
| Alimentazione motore | 230 | Vac 50Hz |
| Assorbimento motore | 2.5 | A |
| Peso massimo del cancello | 4000 | Kg |
| Spinta massima | 3700 | N |
| Servizio | 80 | % |
| Cicli giornalieri consigliati | 200 | n° |
| Grado di protezione | 54 | IP |
| Centrale di comando | CT INVERTER* |
|
