IND4000 V/T WITH CT3IND Irreversible oil bath motor for intensive use

ALLMATIC 12007104 IND4000 V/T WITH CT3IND Irreversible oil bath motor for intensive use

MT Code: ALL_12007104
Manufacturer Code: 12007104
Brand: ALLMATIC

IND4000 V/T WITH CT3IND IND4000

has mechanical components in metal and bronze and an advanced system for the maximum cooling efficiency that guarantee optimal use even in more critical situations, always maintaining a fluid and precise movement, thank you too to the revolutionary electronic control systems integrated. Available in 230 Vac three-phase version (IND4000V/I) and 400Vac three-phase (IND4000V/T). Built to last. Ideal operator for industrial sliding gates up to 4000 Kg.

Irreversible oil-soaked motor for intensive use, with M4 transmission gear and self-ventilation. Complete with CT3IND control unit.

400 Vac three-phase power supply for control unit and motor.

Data Sheet

Feature	Value	Unit of measure
Codice Produttore	12007104
Brand	ALLMATIC
Operatore	IND4000V/T
Alimentazione	400Vac 50Hz
Alimentazione motore	400Vac 50Hz
Assorbimento motore	1.5	A
Peso massimo del cancello	4000	Kg
Spinta massima	3700	N
Servizio	90	%
Cicli giornalieri consigliati	200	n°
Grado di protezione	54	IP
Centrale di comando	CT3IND
