NICE OLTRE1824 Irreversible motor, 24 Vdc

Irreversible motor, 24 Vdc, can be integrated into the column or leaf profile, complete with release lever. For swing gates up to 100 kg and leaf length up to 1.8 m. Concealed mounting.

Retractable motor for swing gates up to 100 kg and leaf length up to 1.8 m
24 Vdc irreversible electromechanical gearmotor.

Minimal visual impact
Small size. The motor can be installed in gate leaf profiles or inside very thin columns (minimum diameter 55 mm).

Simple to install
With installation from below, fixing the motor in the column is facilitated.

Resistant
Die-cast aluminum structure, IP67: It also resists the harshest atmospheric conditions.

Fast and reliable
Complete opening of the door (90°) in approximately 10 seconds. Motor tested for use of 60 cycles/hour, therefore suitable for intensive use.

Safe
Easily usable external manual release: manual opening always possible without dismantling the gate.

Moonclever MC824L dedicated control unit:
• simple programming;
• self-learning of the opening and closing limit switches;
• self-diagnosis of anomalies;
• programming of break time;
• pedestrian gate;
• slowdown in opening and closing;
• dual technology obstacle detection;
• operation in the absence of power with optional rechargeable batteries (PS324)
• prepared for the connection of sensitive edges.
