ZENNIO ZVIIWOKW KNX code keyboard, white

The ZENNIO ZVIIWOKW device, also known as AllInbox 1612, is a multifunctional system designed for the control and management of plants, integrating all the necessary functionality in a single compact device of 12 DIN units.

Key Features

This device includes a 640 mA KNX power supply, a KNX-IP interface, a climate controller with up to 4 independent thermostats, a logic module and a multifunctional actuator with 12 inputs and 16 outputs (16 A C-Load).

Power supply and interface

The 640 mA KNX power supply ensures adequate power stability for all system components. The KNX-IP interface allows efficient and reliable communication within the KNX network.

Climate Controller

The climate controller supports up to 4 independent thermostats, offering precise and customizable climate management in different areas of the plant.

Logic Module

The logic module makes it possible to implement complex and customized logics to manage various aspects of the plant, improving the efficiency and flexibility of the system.

Multifunctional Actuator

The multifunctional actuator has 12 inputs and 16 outputs, which can be configured as individual outputs, roller shutter channels or fan coil controllers. This flexibility allows the device to be adapted to different control and management needs.

Possible Configurations

• Individual outputs for controlling specific devices.
• Roller shutter channels for managing openings.
• Fan coil controller for climate regulation in conditioned environments.

This device, although it has been replaced by the AllInbox 1612 v2 version, still offers a wide range of features and configurations, making it a reliable choice for plant management.
