INIM FIRE SE138KG Catalytic LPG detector - 4÷20mA output and 4 relay outputs
- MT Code
- INM_SE138KG
- Manufacturer Code
- SE138KG
- Brand
- INIM FIRE
LPG detector (catalytic). 4÷20mA output and 4 relay outputs. Measurement range 0÷20 LIE percentage. ATEX ZONE 1
Gas detectors in explosion-proof enclosure for use in areas with the presence of potentially explosive atmospheres, certified CESI 03 ATEX 323 X (EN60079-0 and EN60079-1) are characterized by the following ATEX marking (Directive 2014/34/EU)
12÷24Vcc power supply - Atex marking: II 2G Ex d IIC T6 Gb - No. 3 solid state alarm relay. MAX 24V/1A SPST resistive load - No. 1 solid state fault relay. MAX 24V/1A SPST resistive load - Alarm levels (Relay) programmable via Dip-Switch - No. 1 linear output 4÷20 mA - Polarized plug-in terminals
Detected gas: LPG - Cartridge change: ZSK01/EX - Measuring range: 0÷ 20% LFL - Calibration cylinder: BO200 - Average life in clean air: 5 years
| Feature | Value | Unit of measure |
|---|---|---|
| Codice Produttore | SE138KG | |
| Brand | INIM FIRE |
