ZENNIO ZCL4H230V2 Max Inbox Heating, 4 channels, 230 V

<p/the ZENNIO ZCL4H230V2 product, called HeatingBox 230V 4X v2, is an actuator for air conditioning systems based on water pipes, designed to control up to 4 outputs for on/off valves operated at 230 VAC.

Key Features

This actuator uses triacs with short circuit protection to control outputs. Each outlet is equipped with an independent thermostat, allowing precise temperature control.

Input and Output

The actuator includes 4 analog-digital inputs and 4 outputs for valve control. All outputs are powered by a single power input, with a common neutral to simplify valve installation.

Control and Indications

The outputs can be controlled manually, with status indications through LEDs. This functionality ensures easy and intuitive management of the system.

Logical Functions

The actuator has a module with 10 independent logic functions, offering flexibility and customization in the control of the air conditioning system.

Installation and Use

The installation is facilitated by the presence of a single power input and a common neutral for all outputs. This design greatly simplifies the wiring and configuration of the system.

• Control of up to 4 outputs for on/off valves at 230 VAC
• Independent thermostat for each output
• 4 analog-digital inputs
• 10 independent logical functions
• Manual control of outputs with status indications through LEDs
• Single power input and common neutral for all outputs
