JUNG AL2074NABS Standard 4-channel button sensor - for KNX 2070U bus coupler and 40FW radio transmitter - Metal-aluminium models

KNX push-button, 4-gang ETS-product family: Push-button Product type: 4-gang push-button The 4-gang push-button is plugged onto a flush mounted bus coupling unit. With an appropriate application program, it sends telegrams, for example, to actuators for switching on/off lights, for dimming lights, for recalling and saving light scenes, or for moving blinds/shutters up or down and for adjusting the louvres of blinds. Status and operation indication is possible with 5 LEDs. Software applications: Switching with status 102E01 Vers. 1 Switching with transmission control 102F01 Vers. 1 Dimming 102D01 Vers. 1 Shutter 102C01 Vers. 1 Value transmitting 101D01 Vers. 1 Technical data Supply Voltage: 24 V DC (+6 V / -4 V) via BCU Power consumption: max. 150 mW Connection: 2 x 5-pole pin bar Protection: IP 20 Insulation voltage: referring to VDE 0829 part 230 Behaviour at Bus voltage drop: Object values will be set to "0". LEDs are going off, no telegram is sent. Bus voltage return: Object values remain to "0". LEDs remain off, no telegram is sent. Operation temperature: -5°C ... +45°C Storage temperature: -25°C ... +75°C Mounting: plugged onto a flush mounted BCU
