ARCUS-EDS 90800310 T-PM-10

ARCUS-EDS 90800310 Product Description

The ARCUS-EDS 90800310 product, known as Touch-it AC4, is a touch screen control panel designed for building automation applications. This device features a 4.3 inch color TFT display with 320 x 240 RGB resolution and an intuitive touch screen interface.

Technical characteristics

The Touch-it AC4 is equipped with a 32-bit ARM processor clocked at 1 GHz and 8 GByte of flash memory. It also has a microSD card slot (compatible with SD and SDHC) and a microUSB port.

The device uses the Linux operating system and includes an integrated infrared sensor (AC35) and an integrated temperature sensor (PC35).

Control Features

• Completely programmable through ETS5®, with login possible via USB.
• Support for different themes (light and dark) and up to 6 pages with up to 8 control elements each.
• Each control element can manage up to 4 KNX objects.
• Timer functions, weekly time profiles and solar time control.
• PIN protection for individual items or pages.
• Combinable control functions for heating and cooling applications.
• Setpoint temperature for Comfort, Standby, Economy and Protection.
• Parameterable controller output 0..100% or PWM for thermal drives.

Interface and Sensors

• Two binary inputs and two additional binary inputs (SK30).
• Two front buttons (Push Buttons, SK30) or rotary regulator instead of the front buttons.
• Light control as a switch or button with short, long and double press functions.
• Dimmer and control of curtains and blinds.
• Sensors for temperature, air quality (CO2 or VOC), and brightness (Lux).
• Air temperature measurement (sensor in the case) also weighed with mixed external temperature.
• Relative humidity detection, alarm for heat and frost, and calculation values for absolute humidity, dew temperature and energy content (enthalpy).

Installation and Security

• Horizontal or vertical mounting possible, with mounting ring for 60/68mm recessed boxes (also compatible with Swiss Feller boxes).
• Security against theft thanks to a hidden star screw.
• Aluminium case with dimensions 80.5 x 128 x 10.5 mm and small installation depth.
• IP65 protection class.
