TECNOCONTROL TS593IC2 4-20mA Ex-d ATEX infrared CO2 detector with display - 5% Vol.

MT Code: TCC_TS593IC2
Manufacturer Code: TS593IC2
Brand: TECNOCONTROL

Description

4-20mA Ex-d ATEX infrared CO2 detector with display - 5% Vol.

Gas detectors in explosion-proof housing for use in areas with potentially explosive atmospheres, certified CESI 03 ATEX 323 X (EN60079-0 and EN60079-1) are characterized by the following ATEX marking (Directive 2014/34/EU)

• Power supply: 12÷24 Vcc
• Atex marking: II 2G Ex d IIC T6 Gb
• No. 1 linear output 4÷20 mA • Polarized plug-in terminals
• Provided with a display with real-time display of the gas concentration
• Non-intrusive calibration

Detected Gas: Carbon Dioxide Replacement
cartridge: ZSI01C/EX Measuring
range: 0÷ 5% Vol.
Calibration cylinder: B0405 Average
life in clean air: >5 years
