FAAC TIME-S-DPS UNIQUE+LCD DISPLAY SPineT BUS CONNECTION

Main features

• Readers to be connected to a control unit that implements the connection through the new SpineT bus Maximum total length of the SpineT
• bus: 200 m (maximum 8 readers that can be connected to a single bus)
• 1 relay outputs and 2 digital inputs protected against voltages
• Available with different reading technologies: Magnetic, 125 kHz Unique, HID, 13.56 MHz MIFARE Available in multiple versions with
or without keyboard with or without display
• Version with information display for calendar display with date and time, messages relating to
the
• titles used (valid card, invalid, after hours, etc.), information messages sent with a central computer
• Acoustic signaling with built-in buzzer Versions with
• keyboard for entering a PIN code associated with the card used (double security), codes for activating or deactivating systems (e.g. alarm system), supporting codes,
unit
• programming of
control
• Burglary sensor
• Plastic container with a modern design with painted and customizable cover
• Suitable for installation in a covered indoor or outdoor environment
• Dimensions: H 170 x W 110 x D 70 mm
